90 Series Explosion-proof AC Servo Motor

  • 90 Series Explosion-proof AC Servo Motor

Availability:
Quantity:

Product Description

Description of Explosion proof servo motor 90EX series

"Explosion-proof Servo Motors," which are designed to be used in hazardous or explosive environments, where there is a risk of ignition due to the presence of flammable gases, liquids, or dust.


Technical Parameter of Explosion proof servo motor 90EX series

Motor Model

Motor Model L(mm)
90ST-口00630-EX-XXV(J)/90ST-口00630-EX-XXV 164.5
90ST-口01330-EX-XXV(J)/90ST-口01330-EX-XXV
170.5
90ST-口02430-EX-XXV(J)/90ST-口02430-EX-XXV
198.5
90ST-口03330B-EX-XXV(J)/90ST-口03330-EX-XXV 232.5
90ST-口00630B-EX-XXV(J)/90ST-口00630B-EX-XXV 199.5
90ST-口01330B-EX-XXV(J)/90ST-口01330B-EX-XXV 205.5
90ST-口02430B-EX-XXV(J)/90ST-口02430B-EX-XXV 233.5
90ST-口03330B-EX-XXV(J)/90ST-口03330B-EX-XXV 267.5
90ST-口01330-EX-XXV(J-5P) 165
90ST-口02430-EX-XXV(J-5P) 175
90ST-口03330-EX-XXV(J-5P)
195
90ST-口04030-EX-XXV(J-5P) 205
90ST-口01330B-EX-XXV(J-5P) 190
90ST-口02430B-EX-XXV(J-5P) 200
90ST-口03330B-EX-XXV(J-5P)
220
90ST-口04030B-EX-XXV(J-5P) 230


Motor Dimensions

90防爆ⅡB

Electrical Parameters

Main performance parameters
Motor Model 90ST-口00630-EX 90ST-口01330-EX 90ST-口02430-EX 90ST-口03330-EX
Rated Power(KW) 0.2 0.4 0.75 1.0
Rated Current(A) 1.1 2.1 3.8 4.5
Rated Speed(RPM) 3000 3000 3000 3000
Maximum Speed(RPM) 3600 3600 3600 3600
Rated Torque(NM) 0.6 1.3 2.4 3.3
Maximum Torque(NM) 1.8 3.9 7.2 9.9
Rotor of Inertia(kg.cm²) 0.3 0.6 0.9 1.2

Main performance parameters
Motor Model 90ST-口00630-EX-380V 90ST-口01330-EX-380V 90ST-口02430-EX-380V 90ST-口03330-EX-380V
Rated Power(KW) 0.2 0.4 0.75 1.0
Rated current(A) 0.6 1.05 1.98 2.6
Rated speed(RPM) 3000 3000 3000 3000
Maximum speed(RPM) 3600 3600 3600 3600
Rated Torque(NM) 0.6 1.3 2.4 3.3
Maximum Torque(NM) 1.8 3.9 7.2 9.9
Rotor of Inertia(kg.cm²) 0.3 0.6 0.9 1.2


Torque-Speed Characteristics Curve

1

90ST-口00630-EX


2

90ST-口01330-EX

3

90ST-口02430-EX

90ST-□-03330-EX-XXV

90ST-口03330-EX









Application Industry

  1. Special areasy

  2. Mining Industry

  3. Pharmaceutical Industry

  4. Petrochemical industry

  5. Machinery industry

  6. AGV

  7. Special vehicles

  8. Storage

FAQ

Why do you need a custom motor?


1)Global trade, market diversification, diversified consumer demand, the The trend of individualization is obvious, backing up to the upstream industry to have more special spare parts requirements for new processes and new processing equipment.


2)The World's future long-term national policy guidelines for supply-side reform, elimination of backward production capacity, environmentally friendly, energy-saving, intelligent and safe, the entire industrial environment are in transition, the original batch, large-scale production can not meet market needs.


3)Industrial homogenization competition is extremely serious, the survival environment is worrying; a large number of enterprises seeking change, in response to national policies, the trend of the times, close to customers, to solve customer personalization, targeted problems, personalization has become an important way of industrial production.


4)Electrification, automation, intelligence is the future trend, these can not be separated from the motor, so the future development trend of the motor industry is obvious, especially the personalized non-standard custom motor, market demand is more objective.
