130 Series Explosion-proof DC Servo Motor
| Quantity: | |
|---|---|
Product Description
"Explosion-proof DC Servo Motors," which are designed to be used in hazardous or explosive environments, where there is a risk of ignition due to the presence of flammable gases, liquids, or dust.
| Motor Model | L(mm) |
130ST-口025XX-EX-XXV | 253 |
| 130ST-口040XX-EX-XXV | 253 |
| 130ST-口060XX-EX-XXV | 264 |
| 130ST-口077XX-EX-XXV | 278 |
| 130ST-口100XX-EX-XXV | 312 |
| 130ST-口150XX-EX-XXV | 346 |
| 130ST-口025XXB-EX-XXV | 278 |
| 130ST-口040XXB-EX-XXV | 278 |
| 130ST-口060XXB-EX-XXV | 289 |
| 130ST-口077XXB-EX-XXV | 303 |
| 130ST-口100XXB-EX-XXV | 337 |
| 130ST-口150XXB-EX-XXV | 372 |
| 130ST-口025XX-EX-XXV-C/130ST-口025XX-EX-XXV-C(J) | 235 |
| 130ST-口040XX-EX-XXV-C/130ST-口040XX-EX-XXV-C(J) | 235 |
| 130ST-口060XX-EX-XXV-C/130ST-口060XX-EX-XXV-C(J) | 245 |
| 130ST-口077XX-EX-XXV-C/130ST-口077XX-EX-XXV-C(J) | 260 |
| 130ST-口100XX-EX-XXV-C/130ST-口100XX-EX-XXV-C(J) | 296 |
| 130ST-口150XX-EX-XXV-C/130ST-口150XX-EX-XXV-C(J) | 330 |
| 130ST-口025XXB-EX-XXV-C/130ST-口025XXB-EX-XXV-C(J) | 260 |
| 130ST-口040XXB-EX-XXV-C/130ST-口040XXB-EX-XXV-C(J) | 260 |
| 130ST-口060XXB-EX-XXV-C/130ST-口060XXB-EX-XXV-C(J) | 270 |
| 130ST-口077XXB-EX-XXV-C/130ST-口077XXB-EX-XXV-C(J) | 285 |
| 130ST-口100XXB-EX-XXV-C/130ST-口100XXB-EX-XXV-C(J) | 321 |
| 130ST-口150XXB-EX-XXV-C/130ST-口150XXB-EX-XXV-C(J) | 355 |
| 130ST-口040XX-EX-XXV(J-5P) | 181 |
| 130ST-口060XX-EX-XXV(J-5P) | 196 |
| 130ST-口077XX-EX-XXV(J-5P) | 211 |
| 130ST-口100XX-EX-XXV(J-5P) | 231 |
| 130ST-口150XX-EX-XXV(J-5P) | 241 |
| 130ST-口040XXB-EX-XXV(J-5P) | 211 |
| 130ST-口060XXB-EX-XXV(J-5P) | 226 |
| 130ST-口077XXB-EX-XXV(J-5P) | 241 |
| 130ST-口100XXB-EX-XXV(J-5P) | 261 |
| 130ST-口150XXB-EX-XXV(J-5P) | 271 |
| 130ST-口040XX-EX-XXV(H) | 235 |
| 130ST-口060XX-EX-XXV(H) | 245 |
| 130ST-口077XX-EX-XXV(H) | 260 |
| 130ST-口100XX-EX-XXV(H) | 296 |
| 130ST-口150XX-EX-XXV(H) | 330 |
| 130ST-口040XXB-EX-XXV(H) | 260 |
| 130ST-口060XXB-EX-XXV(H) | 270 |
| 130ST-口077XXB-EX-XXV(H) | 285 |
| 130ST-口100XXB-EX-XXV(H) | 321 |
| 130ST-口150XXB-EX-XXV(H) | 355 |
| 130ST-口040XX-EX-XXV(H-5P) | 181 |
| 130ST-口060XX-EX-XXV(H-5P) | 196 |
| 130ST-口077XX-EX-XXV(H-5P) | 211 |
| 130ST-口100XX-EX-XXV(H-5P) | 231 |
| 130ST-口150XX-EX-XXV(H-5P) | 241 |
| 130ST-口040XXB-EX-XXV(H-5P) | 211 |
| 130ST-口060XXB-EX-XXV(H-5P) | 226 |
| 130ST-口077XXB-EX-XXV(H-5P) | 241 |
| 130ST-口100XXB-EX-XXV(H-5P) | 261 |
| 130ST-口150XXB-EX-XXV(H-5P) | 271 |
Motor Dimensions
Terminal-type motor Lead wire-type motor
Explosion-proof aviation connector type motor
Electrical Parameters
| Main performance parameters | ||||
| Motor Model | 130ST-口04030-EX-24V | 130ST-口06030-EX-24V | 130ST-口07725-EX-24V | 130ST-口10025-EX-24V |
| Rated Power(KW) | 1.2 | 1.8 | 2.0 | 2.5 |
| Rated current(A) | 62.5 | 93.8 | 104.2 | 130.2 |
| Rated speed(RPM) | 3000 | 3000 | 2500 | 2500 |
| Maximum speed(RPM) | 3600 | 3600 | 3000 | 3000 |
| Rated Torque(NM) | 4.0 | 6.0 | 7.7 | 10.0 |
| Maximum Torque(NM) | 12.0 | 18.0 | 23.1 | 30.0 |
| Rotor of Inertia(kg.cm²) | 8.5 | 12.6 | 15.3 | 21.4 |
| Main performance parameters | ||||
| Motor Model | 130ST-口04030-EX-48V | 130ST-口06030-EX-48V | 130ST-口07730-EX-48V | 130ST-口10030-EX-48V |
| Rated Power(KW) | 1.2 | 1.8 | 2.4 | 3.0 |
| Rated current(A) | 29.4 | 44.1 | 58.8 | 73.5 |
| Rated speed(RPM) | 3000 | 3000 | 3000 | 3000 |
| Maximum speed(RPM) | 3600 | 3600 | 3600 | 3600 |
| Rated Torque(NM) | 4.0 | 6.0 | 7.7 | 10.0 |
| Maximum Torque(NM) | 12.0 | 18.0 | 23.1 | 30.0 |
| Rotor of Inertia(kg.cm²) | 8.5 | 12.6 | 15.3 | 21.4 |
| Main performance parameters | ||||
| Motor Model | 130ST-口04030-EX-72V | 130ST-口06030-EX-72V | 130ST-口07730-EX-72V | 130ST-口10030-EX-72V |
| Rated Power(KW) | 1.2 | 1.8 | 2.4 | 3.0 |
| Rated current(A) | 19.6 | 29.4 | 39.2 | 49.0 |
| Rated speed(RPM) | 3000 | 3000 | 3000 | 3000 |
| Maximum speed(RPM) | 3600 | 3600 | 3600 | 3600 |
| Rated Torque(NM) | 4.0 | 6.0 | 7.7 | 10.0 |
| Maximum Torque(NM) | 12.0 | 18.0 | 23.1 | 30.0 |
| Rotor of Inertia(kg.cm²) | 8.5 | 12.6 | 15.3 | 21.4 |
Torque-Speed Characteristics Curve
130ST-口02530-EX-XXV
130ST-口04030-EX-XXV
130ST-口06030-EX-XXV
130ST-口07730-EX-XXV
130ST-口10030-EX-XXV
130ST-口15030-EX-XXV
