110 Explosion-Proof DC Servo Motor
| Quantity: | |
|---|---|
Product Description
"Explosion-proof DC Servo Motors," which are designed to be used in hazardous or explosive environments, where there is a risk of ignition due to the presence of flammable gases, liquids, or dust.
Motor Model
| Motor Model | L(mm) |
| 110ST-口020XX-EX-XXV | 227 |
| 110ST-口040XX-EX-XXV | 252 |
| 110ST-口060XX-EX-XXV | 282 |
| 110ST-口020XXB-EX-XXV | 252 |
| 110ST-口040XXB-EX-XXV | 277 |
| 110ST-口060XXB-EX-XXV | 307 |
| 110ST-口020XX-EX-XXV-C | 225 |
| 110ST-口040XX-EX-XXV-C | 250 |
| 110ST-口060XX-EX-XXV-C | 280 |
| 110ST-口020XXB-EX-XXV-C | 250 |
| 110ST-口040XXB-EX-XXV-C | 275 |
| 110ST-口060XXB-EX-XXV-C | 305 |
| 110ST-口020XX-EX-XXV-C(J) | 195 |
| 110ST-口040XX-EX-XXV-C(J) | 220 |
| 110ST-口060XX-EX-XXV-C(J) | 250 |
| 110ST-口020XXB-EX-XXV-C(J) | 220 |
| 110ST-口040XXB-EX-XXV-C(J) | 245 |
| 110ST-口060XXB-EX-XXV-C(J) | 275 |
Motor Dimensions
Electrical Parameters
| Main performance parameters | |||
| Motor Model | 110ST-口02030-EX-24V | 110ST-口04030-EX-24V | 110ST-口06020-EX-24V |
| Rated Power(KW) | 0.6 | 1.2 | 1.2 |
| Rated current(A) | 31.3 | 62.5 | 62.5 |
| Rated speed(RPM) | 3000 | 3000 | 2000 |
| Maximum speed(RPM) | 3600 | 3600 | 2400 |
| Rated Torque(NM) | 2 | 4 | 6 |
| Maximum Torque(NM) | 6 | 12 | 18 |
| Rotor of Inertia(kg.cm²) | 3.1 | 5.4 | 7.6 |
| Main performance parameters | |||
| Motor Model | 110ST-口02030-EX-48V | 110ST-口04030-EX-48V | 110ST-口06030-EX-48V |
| Rated Power(KW) | 0.6 | 1.2 | 1.8 |
| Rated current(A) | 14.7 | 29.4 | 44.1 |
| Rated speed(RPM) | 3000 | 3000 | 3000 |
| Maximum speed(RPM) | 3600 | 3600 | 3600 |
| Rated Torque(NM) | 2 | 4 | 6 |
| Maximum Torque(NM) | 6 | 12 | 18 |
| Rotor of Inertia(kg.cm²) | 3.1 | 5.4 | 7.6 |
| Main performance parameters | |||
| Motor Model | 110ST-口02030-EX-72V | 110ST-口04030-EX-72V | 110ST-口06030-EX-72V |
| Rated Power(KW) | 0.6 | 1.2 | 1.8 |
| Rated current(A) | 9.8 | 19.6 | 29.4 |
| Rated speed(RPM) | 3000 | 3000 | 3000 |
| Maximum speed(RPM) | 3600 | 3600 | 3600 |
| Rated Torque(NM) | 2 | 4 | 6 |
| Maximum Torque(NM) | 6 | 12 | 18 |
| Rotor of Inertia(kg.cm²) | 3.1 | 5.4 | 7.6 |
Torque-Speed Characteristics Curve
110ST-口02030-EX
110ST-口04030-EX
110ST-口06030-EX
Application Industry
Special areasy
Mining Industry
Pharmaceutical Industry
Petrochemical industry
Machinery industry
AGV
Special vehicles
Storage
