220 Series Explosion-proof DC Servo Motor

Description of Explosion proof servo motor 220 EX series

"Explosion-proof DC Servo Motors," which are designed to be used in hazardous or explosive environments, where there is a risk of ignition due to the presence of flammable gases, liquids, or dust.

Technical Parameter of Explosion proof servo motor 220 EX series

Motor Model

Motor Model	L(mm)
220ST-口400XX-EX-XXV	374
220ST-口600XX-EX-XXV	420
220ST-口750XX-EX-XXV	454
220ST-口850XX-EX-XXV	474
220ST-口10AXX-EX-XXV	524
220ST-口12AXX-EX-XXV	574
220ST-口15AXX-EX-XXV	624
220ST-口400XXB-EX-XXV	469
220ST-口600XXB-EX-XXV	519
220ST-口750XXB-EX-XXV	549
220ST-口850XXB-EX-XXV	569
220ST-口10AXXB-EX-XXV	619
220ST-口12AXXB-EX-XXV	669
220ST-口15AXXB-EX-XXV	719
220ST-口400XX-EX-XXV(J)	409
220ST-口600XX-EX-XXV(J)	459
220ST-口750XX-EX-XXV(J)	489
220ST-口850XX-EX-XXV(J)	509
220ST-口10AXX-EX-XXV(J)	559
220ST-口12AXX-EX-XXV(J)	609
220ST-口15AXX-EX-XXV(J)	659
220ST-口400XXB-EX-XXV(J)	499
220ST-口600XXB-EX-XXV(J)	549
220ST-口750XXB-EX-XXV(J)	579
220ST-口850XXB-EX-XXV(J)	599
220ST-口10AXXB-EX-XXV(J)	649
220ST-口12AXXB-EX-XXV(J)	699
220ST-口15AXXB-EX-XXV(J)	749

Motor Dimensions

Electrical Parameters

Main performance parameters
Motor Model	220ST-口40030-EX-48V	220ST-口60020-EX-48V	220ST-口75015-EX-48V
Rated Power(KW)	12.0	12.0	11.0
Rated current(A)	294.0	294.0	270.0
Rated speed(RPM)	3000	2000	1500
Maximum speed(RPM)	3600	2400	1800
Rated Torque(NM)	40.0	60.0	75.0
Maximum Torque(NM)	80.0	120.0	150.0
Rotor of Inertia(kg.cm²)	98.0	147.0	176.0

Main performance parameters
Motor Model	220ST-口85015-EX-48V	220ST-口10A10-EX-48V
Rated Power(KW)	13.0	10.0
Rated current(A)	319.0	245.0
Rated speed(RPM)	1500	1000
Maximum speed(RPM)	1800	1200
Rated Torque(NM)	85.0	100.0
Maximum Torque(NM)	170.0	200.0
Rotor of Inertia(kg.cm²)	196.0	245.0

Main performance parameters
Motor Model	220ST-口40030-EX-72V	220ST-口60030-EX-72V	220ST-口75025-EX-72V
Rated Power(KW)	12.0	18.0	19.0
Rated current(A)	196.0	294.0	310.0
Rated speed(RPM)	3000	3000	2500
Maximum speed(RPM)	3600	3600	3000
Rated Torque(NM)	40.0	60.0	75.0
Maximum Torque(NM)	80.0	120.0	150.0
Rotor of Inertia(kg.cm²)	98.0	147.0	176.0

Main performance parameters
Motor Model	220ST-口85025-EX-72V	220ST-口10A20-EX-72V	220ST-口12A15-EX-72V
Rated Power(KW)	22.0	20.0	18.0
Rated current(A)	359.0	327.0	294.0
Rated speed(RPM)	2500	2000	1500
Maximum speed(RPM)	3000	2400	1800
Rated Torque(NM)	85.0	100.0	120.0
Maximum Torque(NM)	170.0	200.0	240.0
Rotor of Inertia(kg.cm²)	196.0	245.0	294.0

Main performance parameters
Motor Model	220ST-口40030-EX-96V	220ST-口60030-EX-96V	220ST-口75030-EX-96V	220ST-口85030-EX-96V
Rated Power(KW)	12.0	18.0	23.0	26.0
Rated current(A)	147.0	221.0	282.0	319.0
Rated speed(RPM)	3000	3000	3000	3000
Maximum speed(RPM)	3600	3600	3600	3600
Rated Torque(NM)	40.0	60.0	75.0	85.0
Maximum Torque(NM)	80.0	120.0	150.0	170.0
Rotor of Inertia(kg.cm²)	98.0	147.0	176.0	196.0

Main performance parameters
Motor Model	220ST-口10A25-EX-96V	220ST-口12A20-EX-96V	220ST-口15A15-EX-96V
Rated Power(KW)	25.0	25.0	23.0
Rated current(A)	306.0	306.0	282.0
Rated speed(RPM)	2500	2000	1500
Maximum speed(RPM)	3000	2400	1800
Rated Torque(NM)	100.0	120.0	150.0
Maximum Torque(NM)	200.0	240.0	300.0
Rotor of Inertia(kg.cm²)	245.0	294.0	343.0

Main performance parameters
Motor Model	220ST-口40030-EX-144V	220ST-口60030-EX-144V	220ST-口75030-EX-144V	220ST-口85030-EX-144V
Rated Power(KW)	12.0	18.0	23.0	26.0
Rated current(A)	98.0	147.0	188.0	212.0
Rated speed(RPM)	3000	3000	3000	3000
Maximum speed(RPM)	3600	3600	3600	3600
Rated Torque(NM)	40.0	60.0	75.0	85.0
Maximum Torque(NM)	80.0	120.0	150.0	170.0
Rotor of Inertia(kg.cm²)	98.0	147.0	176.0	196.0

Main performance parameters
Motor Model	220ST-口10A30-EX-144V	220ST-口12A20-EX-144V	220ST-口15A25-EX-144V
Rated Power(KW)	30.0	36.0	39.0
Rated current(A)	245.0	294.0	319.0
Rated speed(RPM)	3000	3000	2500
Maximum speed(RPM)	3600	3600	3000
Rated Torque(NM)	100.0	120.0	150.0
Maximum Torque(NM)	200.0	240.0	300.0
Rotor of Inertia(kg.cm²)	245.0	294.0	343.0

Main performance parameters
Motor Model	220ST-口40030-EX-310V	220ST-口60030-EX-310V	220ST-口75030-EX-310V	220ST-口85030-EX-310V
Rated Power(KW)	12.0	18.0	23.0	26.0
Rated current(A)	53.0	80.0	102.0	115.0
Rated speed(RPM)	3000	3000	3000	3000
Maximum speed(RPM)	3600	3600	3600	3600
Rated Torque(NM)	40.0	60.0	75.0	85.0
Maximum Torque(NM)	80.0	120.0	150.0	170.0
Rotor of Inertia(kg.cm²)	98.0	147.0	176.0	196.0

Main performance parameters
Motor Model	220ST-口10A30-EX-310V	220ST-口12A30-EX-310V	220ST-口15A30-EX-310V
Rated Power(KW)	30.0	36.0	45.0
Rated current(A)	133.0	160.0	200.0
Rated speed(RPM)	3000	3000	2500
Maximum speed(RPM)	3600	3600	3000
Rated Torque(NM)	100.0	120.0	150.0
Maximum Torque(NM)	200.0	240.0	300.0
Rotor of Inertia(kg.cm²)	245.0	294.0	343.0

Main performance parameters
Motor Model	220ST-口40030-EX-540V	220ST-口60030-EX-540V	220ST-口75030-EX-540V	220ST-口85030-EX-540V
Rated Power(KW)	12.0	18.0	23.0	26.0
Rated current(A)	31.0	46.0	59.0	66.0
Rated speed(RPM)	3000	3000	3000	3000
Maximum speed(RPM)	3600	3600	3600	3600
Rated Torque(NM)	40.0	60.0	75.0	85.0
Maximum Torque(NM)	80.0	120.0	150.0	170.0
Rotor of Inertia(kg.cm²)	98.0	147.0	176.0	196.0

Main performance parameters
Motor Model	220ST-口10A30-EX-540V	220ST-口12A30-EX-540V	220ST-口15A30-EX-540V
Rated Power(KW)	30.0	36.0	45.0
Rated current(A)	76.0	92.0	115.0
Rated speed(RPM)	3000	3000	3000
Maximum speed(RPM)	3600	3600	3600
Rated Torque(NM)	100.0	120.0	150.0
Maximum Torque(NM)	200.0	240.0	300.0
Rotor of Inertia(kg.cm²)	245.0	294.0	343.0

Torque-Speed Characteristics Curve

220ST-口40030-EX-XXV

220ST-口60030-EX-XXV

220ST-口75030-EX-XXV

220ST-口85030-EX-XXV

220ST-口10A30-EX-XXV

220ST-口12A30-EX-XXV

220ST-口15A30-EX-XXV

1. Special areasy

2. Mining Industry

3. Pharmaceutical Industry

4. Petrochemical industry

5. Machinery industry

6. AGV

7. Special vehicles

8. Storage
