Product Description
Motor Model
| Motor Model | L1(mm) | L2(mm) |
| 80ST-H006XX-XXV | 134 | |
| 80ST-H013XX-XXV | 140 | |
| 80ST-H024XX-XXV | 160 | 170 |
| 80ST-H006XXB-XXV | 189 | |
| 80ST-H013XXB-XXV | 184 | |
| 80ST-H024XXB-XXV | 204 | 214 |
Motor Dimensions
Electrical Parameters
| Main performance parameters | |||
Motor Model | 80ST-H00630-24V | 80ST-H01330-24V | 80ST-H02430-24V |
| Rated Power(KW) | 0.2 | 0.4 | 0.75 |
| Rated current(A) | 10.4 | 20.8 | 39.1 |
| Rated speed(RPM) | 3000 | 3000 | 3000 |
| Maximum Speed(RPM) | 3600 | 3600 | 3600 |
| Rated Torque(NM) | 0.6 | 1.3 | 2.4 |
| Maximum Torque(RPM) | 1.8 | 3.9 | 7.2 |
| Inertia of rotor(kg.cm²) | 0.3 | 0.6 | 0.9 |
| Main performance parameters | |||
Motor Model | 80ST-H00630-48V | 80ST-H01330-48V | 80ST-H02430-48V |
| Rated Power(KW) | 0.2 | 0.4 | 0.75 |
| Rated current(A) | 4.9 | 9.8 | 18.4 |
| Rated speed(RPM) | 3000 | 3000 | 3000 |
| Maximum Speed(RPM) | 3600 | 3600 | 3600 |
| Rated Torque(NM) | 0.6 | 1.3 | 2.4 |
| Maximum Torque(RPM) | 1.8 | 3.9 | 7.2 |
| Inertia of rotor(kg.cm²) | 10.1 | 11.8 | 15.1 |
| Main performance parameters | |||
Motor Model | 80ST-H00630-72V | 80ST-H01330-72V | 80ST-H02430-72V |
| Rated Power(KW) | 0.2 | 0.4 | 0.75 |
| Rated current(A) | 3.3 | 6.5 | 12.3 |
| Rated speed(RPM) | 3000 | 3000 | 3000 |
| Maximum Speed(RPM) | 3600 | 3600 | 3600 |
| Rated Torque(NM) | 0.6 | 1.3 | 2.4 |
| Maximum Torque(RPM) | 1.8 | 3.9 | 7.2 |
| Inertia of rotor(kg.cm²) | 7.2 | 8.4 | 10.8 |
